用途：經粗開松后的原料，由風機通過氣缸旋風頭，將原料呈雪花狀輸送混倉內，原料在儲棉倉儲存，混合。使在不同時間落入倉內的原料，在同一時間被斜簾抓取，經均棉輥及打手將原料送到下道儲棉箱內，供下道工序使用。
Application：Raw material appeared snowflake after rough opened will feed into the transmission mixing cabin via cylinder cyclone head through fan The raw material will be stored and mixed in cotton storage cabinet Raw material fallen into the cabinet at different time will be grasped by incline curtain at same time and will send to next hopper via cotton uniform roll and beater for use at next procedure.
技術參數：Technical parameters
1. 工作寬度Working width：1600mm、1800mm、2000mm
2. 儲棉量Cotton storage quantity：10m³、20m³、35m³
3. 裝機容量Equipped capacity：5.25KW
結構描述：Description of structure
1. 簾子部分由輸出送平簾及角釘斜簾組成，分別由兩個減速機控制。
2. 落棉旋風頭供棉至儲棉倉。
3. 送棉分風機輸送及簾子輸送兩種。
1.The part of curtain consists of output even curtain and brad incline curtain and can be controlled by two speed reducer individually.
2.Cyclone head of noil will supply cotton to cotton storage cabinet
3.The cotton feeding can be divided into two kinds, fan transmission and curtain transmission. |
