| 產品名稱：GICL鼓形齒式聯軸器 |
| 產品編號： |
發布日期：
2019/11/12 |
| 產品產地：江蘇江陰 |
產品規格：可根據用戶需求定制 |
| 產品商標：威宇 |
 |
|
|
|
|
|

| 型號 |
公稱扭矩Tn(N.m) |
許用轉速[n](r/min) |
軸孔直徑d1,d2,dz |
軸孔長度 |
D |
C |
C1 |
C2 |
轉動慣量
Kg.m2 |
重量
Kg |
| Y |
Z1,J1 |
| L |
| GICL1 |
630 |
4000 |
16 18 19 |
42 |
- |
125 |
20 |
- |
- |
0.009 |
5.9 |
| 20 22 24 |
52 |
38 |
- |
24 |
| 25 28 |
62 |
44 |
10 |
- |
19 |
| 30 32 35 38 |
82 |
60 |
2.5 |
15 |
22 |
| GICL2 |
1120 |
4000 |
25 28 |
62 |
44 |
144 |
10.5 |
- |
29 |
0.02 |
9.7 |
| 30 32 35 38 |
82 |
60 |
12.5 |
30 |
| 40 42 45 48 |
112 |
84 |
2.5 |
13.5 |
28 |
| GICL3 |
2240 |
4000 |
30 32 35 38 |
82 |
60 |
174 |
3 |
24.5 |
25 |
0.047 |
17.2 |
| 40 42 45 48 50 55 56 |
112 |
84 |
17 |
28 |
| 60 |
142 |
107 |
35 |
| GICL4 |
3600 |
4000 |
32 35 38 |
82 |
60 |
196 |
14 |
37 |
32 |
0.091 |
24.9 |
| 40 42 45 48 50 55 56 |
112 |
84 |
28 |
| 60 63 65 70 |
142 |
107 |
3 |
17 |
35 |
| GICL5 |
5000 |
3300 |
40 42 45 48 50 55 56 |
112 |
84 |
224 |
3 |
25 |
28 |
0.167 |
38 |
| 60 63 65 70 71 75 |
142 |
107 |
20 |
35 |
| 80 |
172 |
132 |
22 |
43 |
| GICL6 |
7100 |
3000 |
48 50 55 56 |
112 |
84 |
241 |
6 |
35 |
35 |
0.267 |
48.2 |
| 60 63 65 70 71 75 |
142 |
107 |
20 |
35 |
| 80 85 90 |
172 |
132 |
4 |
22 |
43 |
| GICL7 |
10000 |
2680 |
60 63 65 70 71 75 |
142 |
107 |
260 |
4 |
35 |
35 |
0.453 |
68.9 |
| 80 85 90 95 |
172 |
132 |
22 |
43 |
| 100 |
212 |
167 |
48 |
| GICL8 |
14000 |
2500 |
65 70 71 75 |
142 |
107 |
282 |
5 |
35 |
35 |
0.646 |
83.3 |
| 80 85 90 95 |
172 |
132 |
22 |
43 |
| 100 110 |
212 |
167 |
48 |
| GICL9 |
18000 |
2350 |
70 71 75 |
142 |
107 |
314 |
10 |
45 |
45 |
1.036 |
110 |
| 80 85 90 95 |
172 |
132 |
| 100 110 120 125 |
212 |
167 |
5 |
22 |
43 |
| 49 |
| GICL10 |
31500 |
2150 |
80 85 90 95 |
172 |
132 |
346 |
5 |
43 |
43 |
1.88 |
157 |
| 100 110 120 125 |
212 |
167 |
22 |
49 |
| 130 140 |
252 |
202 |
29 |
54 |
| GICL11 |
40000 |
1880 |
100 110 120 125 |
212 |
167 |
380 |
6 |
29 |
49 |
3.28 |
217 |
| 130 140 150 |
252 |
202 |
54 |
| 160 |
302 |
242 |
64 |
| GICL12 |
56000 |
1680 |
120 125 |
212 |
167 |
442 |
6 |
57 |
57 |
5.08 |
305 |
| 130 140 150 |
252 |
202 |
29 |
55 |
| 160 170 180 |
302 |
242 |
68 |
| GICL13 |
80000 |
1530 |
140 150 |
252 |
202 |
482 |
7 |
54 |
57 |
10.06 |
419 |
| 160 170 180 |
302 |
242 |
32 |
70 |
| 190 200 |
352 |
282 |
80 |
| GICL14 |
112000 |
1300 |
160 170 180 |
302 |
242 |
520 |
8 |
42 |
70 |
16.774 |
594 |
| 190 200 220 |
352 |
282 |
32 |
80 |
| GICL15 |
160000 |
1180 |
190 200 220 |
352 |
282 |
580 |
10 |
34 |
80 |
26.55 |
783 |
| 140 150 |
410 |
330 |
38 |
- |
| GICL16 |
250000 |
1000 |
200 220 |
352 |
282 |
680 |
10 |
58 |
80 |
52.22 |
1134 |
| 240 250 260 |
410 |
330 |
38 |
- |
| 280 |
470 |
380 |
38 |
| GICL17 |
280000 |
980 |
220 |
352 |
282 |
720 |
10 |
74 |
80 |
69 |
1305 |
| 240 250 260 |
410 |
330 |
| 280 300 |
470 |
380 |
39 |
- |
| GICL18 |
355000 |
900 |
240 250 260 |
410 |
330 |
775 |
10 |
46 |
- |
96.16 |
1626 |
| 280 300 320 |
470 |
380 |
41 |
- |
| GICL19 |
450000 |
830 |
260 |
410 |
330 |
815 |
10 |
67 |
- |
115.6 |
1773 |
| 280 300 320 |
470 |
380 |
41 |
| 340 |
550 |
450 |
| GICL20 |
500000 |
790 |
280 300 320 |
470 |
380 |
855 |
13 |
44 |
- |
167.41 |
2263 |
| 340 360 |
550 |
450 |
| GICL21 |
630000 |
750 |
300 320 |
470 |
380 |
915 |
13 |
59 |
- |
215.7 |
2593 |
| 340 360 380 |
550 |
450 |
44 | |
| |
|
|
|
|
|
|
|
|
|
